Introduction:
JIC Fitting is a range of hydraulic fittings that is produced in accordance to the SAE J514 standards. The acronym JIC stands for Joint Industry Council. It's likewise known as the JIC 37 degrees flare fitting since it has a thirty seven degrees flare seating area. These fittings are utilized on oil hydraulic methods in fields which are several (fuel delivery, etc...), mobile hydraulic equipment, shipbuilding, fuel power program. A JIC fitting structure has three components which create a tubing assembly: installing, flare nut, and sleeve.

Material:
Materials used-to fabricate JIC fittings are stainless as well as carbon steel SS316L.

Sizes:
JIC body and flare nut are obtainable in outer diameter ("OD) sizes between 1/8" to 1 2". Sleeve has two different reading measurements, metric measurement (mm) & inch exterior diameter ("OD). Sleeve size can be purchased from 3mm to 50mm and 1/8" to 2". Connecting sizes are designated by the corresponding outside diameter of the tubing for the numerous kinds of tube ends.

Working Pressure:
The typical functioning pressure of the fittings ranges from thousand to 5000 psi for various sizes and connections. The minimum burst pressure is 4 times the working pressure. The JIC fittings should be in a position to withstand twice the working strain for a period of 1 minute with no failure or leakage.
Please take note that the strain rating of an exact same fitting may vary when it is connected to distinct equipments.. For example, if a fitting with a minimal performing pressure is attached to a pipe, it will result in a general much lower functioning pressure. In all cases, consistently consider the lowest pressure as the highest working pressure of the product.

Just how does a JIC fitting works: For tube connections, the assembly therapy starts out of the planning of the tube. To begin with, the nut as well as sleeve are inserted onto the conclusion of a hose. With all the use of a flaring tool, form the end of the tube to thirty seven degrees. Next, tighten the nut by using a spanner till the nut is tight as well as the sleeve grips onto the tube. If the fittings are bench put together, the gripping actions might be driven by rotating the tubing using a pair of scissors as the nut is drawn down. When the tubing will not anymore be rotated by hand, the sleeve has gripped onto the tube. If this occurs,, tighten the nut by turning it one full turn. This might vary more or less with different tubing materials, but for general practice, it's an excellent rule to follow.

Configurations of JIC Fitting: Commonly used connection sorts consist of: JIC/BSPP Male Connector, real reviews google; click now, JIC/ NPT Male connector, JIC union, JIC/NPT Swivel Male Connector, JIC/BSPP Swivel Male Connector.

Brand of JIC Fittings:
HS Corporation is a Korean company specializing in JIC Fitting. Started in 1980, HS Corporation has more than thirty years of specialized experience in producing fittings.
